24V Underground Hydraulic Operator

The FAAC S800H ENC is a premium underground swing gate operator that combines advanced hydraulic technology with intelligent 24V control for exceptional performance and reliability.

Designed to remain completely concealed beneath the gate, it delivers powerful, quiet automation while preserving the appearance of the entrance.

Featuring an absolute magnetic encoder, integrated BUS 2easy technology, and patented positive stops, this automatic swing gate opener provides outstanding precision, advanced safety, and dependable operation even in demanding environments. Built for frequent use and engineered to the highest standards, the S800H ENC is the premium swing gate motor choice for projects throughout New Zealand.

Underground operator with hydraulic technology 24V
Absolute magnetic encoder (for ENC models) with integrated BUS 2easy (non polarized two wires connection)
Integrated Positive Stops, possibility to avoid mechanical stops installation. FAAC Patent.

Max Leaf Weight	800 kg
Max single leaf width	2 – 4 m
Use frequency	Continuous use

Technical Description

Download

FAAC_S800H_ENC_Attuatore_Cancelli_Battente_Focus1

Underground Automation Without Compromise

The FAAC S800H ENC has been engineered for projects where premium aesthetics and uncompromising performance are equally important. Installed completely below ground, this hydraulic swing gate motor remains hidden from view while delivering the strength, precision, and reliability FAAC is known for.

By combining proven hydraulic technology with a powerful 24V motor, the S800H ENC is built to handle intensive operating cycles with ease. Integrated positive stops remove the need for separate mechanical stops on many installations, while the absolute magnetic encoder and BUS 2easy communication system provide exceptional control and enhanced safety.

The result is an automatic swing gate opener that offers smooth movement, intelligent operation, and long-term reliability without compromising the appearance of the entrance.

Key features include:

Premium 24V underground hydraulic swing gate operator
Fully concealed installation for a clean architectural finish
Advanced Hybrid hydraulic and 24V DC technology
Absolute magnetic encoder for precise gate positioning
Integrated BUS 2easy two-wire communication
Patented integrated positive stops
Anti-crushing and automatic obstacle detection
Battery backup compatibility during power outages
Premium FAAC engineering built for New Zealand conditions

Contact Us

Focus on S800H ENC Swing Gate Operator

Hybrid Core

By combining FAAC’s hydraulic technology with a 24V DC motor, the S800H ENC becomes a robust, reliable, high-performance operator, perfect for high-frequency use. It also supports battery backup operation in case of power failure.

FAAC_S418_Attuatore_Cancelli_Battente_Focus2

Absolute magnetic encoder with BUS 2easy

Anti-crushing safety and obstacle-reversal functions are ensured by the presence of an absolute magnetic encoder with BUS 2easy technology (connectable via just two non-polarised wires).

In the event of a power outage, the absolute encoder retains the gate leaf position in memory, wherever it stopped.

Technical Infos

Product infos S800H ENC

Technical Description

Model	Item code
S800H ENC CBAC 100°	108720
S800H ENC SBW 100°	108724
S800H ENC CBAC 180°	108722
S800H ENC SBW 180°	108725

Power supply voltage 220-240V ~ 50/60 Hz
Electric motor With brushes 24V DC
Max power 60 W
Max leaf weight 800 kg
Max leaf width 2 – 4 m
Use frequency Continuous use

Download

Catalogue
Manuals

Other Files:
