Sliding Gate Automation
Sliding Gate Operator
Gallery
Technical Infos
Product Information
Technical Description
| Duty | Industrial |
| Power Consumption | 950W |
| Max Gate Weight | 1,600kg (Z16) / 2,200kg (Z12) |
| Max Speed | 9.5 m/min (Z16) / 7.2 m/min (Z12) |
| Use frequency | 70% |
| Special considerations | Control board requires CAT3 safety edges to be used. |
Variants
| Model Variant | Part Number | Application | Use Frequency | Limit Switch Type | Power Supply | Maximum Leaf Weight | Gate Obstacle Detection |
|---|---|---|---|---|---|---|---|
| 844 R 3PH | 109896 | Industrial | 70.00% | Inductive | 3Phase | 2200 | No encoder |
| 844 R 3PH with control board | 109924 | Industrial | 70.00% | Inductive | 3Phase | 2200 | Encoder |
